Place of Origin:
China
Brand Name:
CHASING
Certification:
CE,PED,UL,CSA
Model Number:
ZGF
Contact Us
Main technique parameter
| Model (ZGF) | 601 | 602 | 603 | 604 | 605 | 606 | 607 | 608 | 609 |
| Power(KW) | 1.5 | 4 | 7.5 | 11 | 18.5 | 22 | 37 | 55 | 75 |
| Rotate speed(rpm) | 6000 | 3000 | 3000 | 3000 | 3000 | 3000 | 1500 | 1500 | 1500 |
| High(mm) | 510 | 600 | 700 | 800 | 920 | 930 | 1150 | 1250 | 1380 |
| Cubage(L) | 10~30 | 50~200 | 50~400 | 100~500 | 500~2000 | 800~2500 | 1500~3000 | 2500~5000 | 4000~10000 |
Remark:
The measured medium is water for the max.batch processing capacity in the table;
The batch processing capacity depends on viscosity and solids content of the materials;
Insert in from the top of the vessel,while amounting,it has the requirement for high verticality.
